包装機械用iHFダブテールスライド
Productfeatures:
ダブテールスライドは、内側と外側のダブテール溝が連動する機構を採用し、ガイドと動作をスムーズに行い、移動範囲の拡大、シンプルな構造、そして優れたコスト効率を実現します。当社の製品ラインには、ラック＆ピニオン駆動、フィードスクリュー駆動、リードスクリュー駆動など、様々な駆動方式があり、ラック＆ピニオンシステムを用いたロングストローク用途向けに特別に設計されたモデルも複数あります。これらのスライドは、高速送りや迅速な調整操作に適していますが、高精度な位置決めが求められる用途にはお勧めできません。
精密位置決めステージ:
| Product Model | Manual Z-Axis Stage |
| Material | Aluminum Alloy/Copper Alloy/Brass |
| Module | ZD49BR ZD49BB ZD49JB |
| Motion Direction | Z-axis Horizontal Plane |
| Transport Package | Cartons |
| Trademark | iHF |
| HS Code | 9031900090 |
| Feed Type | Rack and Pinion Driven Lead Screw Driven |
| Surface Treatment | Black Anodized/Black Fluoropolymer |
| Surface Color | Black |
| Application | Precision Electronics, Precision Optics, Laser Processing, Lithium-ion Battery Manufacturing, Optoelectronics |
| Specification | Standard |
| Origin | Dongguan(Mainland) |
| Production Capacity | 100000 PCS/Year |
製品説明:
| Product | Dovetail Groove Gear Rack Stage |
| Customized | OEM, drawings or samples customized |
| Travel Range | ±2.5 ±5 ±10 |
| Specifications | 25 40 60 |
| Platform Dimensions | 25*25 40*40 60*60 |
| Least Count of Micrometer | 0.5mm |
| Material | Aluminum Alloy/Copper Alloy/Brass |
| Positioning Accuracy(µm) | 30µm |
| Unit Weight(kg) | 0.08 0.12 0.47 0.5 |
| Load Capacity(kgf) | 0.7 1 1.5 |
| Key Features | High Precision Positioning, High Rigidity Design, Flexible Configuration, Excellent Protection, Low Noise Operation |
| Application Industry | Automated Production lines; Vision Inspection; Coordinate Measuring Machines; Laser Cutting, Engraving, Dispensing Equipment; Chip Packaging, PCB Processing |
応用
Horizontal Z-axis dovetail slide stages utilize mutually constrained male and female dovetail grooves to form a simple and cost-effective guide mechanism. They offer smooth sliding motion and a relatively long stroke, making them well-suited for rapid feed and quick adjustment applications. However, due to inherent limitations in precision, they are not ideal for fine positioning tasks. Typical applications include general-purpose automation, educational or training setups, and light-duty positioning within 3C electronics testing equipment.
