カスタム高精度CNC加工ステンレス鋼製ストレートスパーギア
今すぐお問い合わせ
小型内部スパーピニオン プラスチック鍛造 IHF
Productfeatures:
従来の機械加工ギアとは異なり、プラスチック鍛造構造は材料密度を最適化し、耐摩耗性を向上させると同時に、全体の重量を大幅に削減します。そのため、効率性とスムーズな噛み合いが重要な軽量機械アセンブリに特に適しています。
内部平歯設計により、相手歯車との正確な噛み合いが保証され、狭い空間でも効率的な動力伝達が可能になります。自動化機器、精密機器、小型ギアボックス、医療機器、事務機器、その他のマイクロメカニカル駆動システムに幅広く使用されています。
主な利点は以下のとおりです。
精密な内歯形状によりスムーズな噛み合いを実現
軽量で高い機械的強度を持つプラスチック鍛造構造
運転中の騒音と振動が少ない
優れた耐摩耗性と長寿命
技術要件に基づいたOEM/ODMカスタマイズに適しています
精密ギア:
| Product Name | helical gear/spur gear |
| Material | Plastic |
| shape | Pinion |
| warranty | 1.5 year |
| machinery test report | Provided |
| Trademark | iHF |
| place of origin | Guangdong, China |
| pressure angle | 20 |
| Material Standard | PA66, POM, PEEK, Nylon, Delrin,etc |
| Heat Treatment | Quenching & Tempering, Carburizing & Quenching |
| Bore | Finished bore, Pilot Bore, Special request |
| Hardness | 55- 60HRC |
| Size | Customer Drawings & ISO standard |
| Gross weight per batch | 2.000 kg |
製品説明:
| Product Name | helical gear/spur gear |
| Material Standard | Stainless Steel, Carbon Steel, Brass, Bronze, Iron, Aluminum Alloy etc |
| Heat Treatment | Quenching & Tempering, Carburizing & Quenching, High-frequency Hardening, Carbonitriding...... |
| Bore | Finished bore, Pilot Bore, Special request |
| Hardness | 55- 60HRC |
| Size | Customer Drawings & ISO standard |
| Certificate | ISO9001:2008 |
| Teeth Number | 10-100 |
| Surface Treatment | Carburizing and Quenching |
| Precision Grade | DIN5 TO DIN7 |
| Machining process | Gear Hobbing, Gear Milling, Gear Shaping, Gear Broaching, Gear Shaving, Gear Grinding and Gear Lapping |
| Processing Method | Molding, Shaving, Hobbing, Drilling, Tapping, Reaming, Manual Chamfering, Grinding etc |
| Package | Wooden Case/Container and pallet, or made-to-order |
| Apllications | Electric machinery, metallurgical machinery, environmental protection machinery, electronic and electrical appliances, road construction machinery, chemical machinery, food machinery, light industrial machinery, mining machinery, transportation machinery, construction machinery, building materials machinery, cement machinery, rubber machinery, water conservancy machinery and petroleum machinery |
応用
The Small Internal Spur Pinion Plastic Forged IHF is a high-performance, compact internal spur pinion widely utilized in various mechanical transmission systems. Thanks to its fabrication via a plastic forging process, it features a lightweight design, excellent wear resistance, and superior corrosion resistance, making it ideally suited for applications in household appliances, toys, automation equipment, robotics, and similar fields.
